5v Car Electric Gauge Meter Sender Air Oil Fuel Pressure Sensor 0-150 Psi

Features: It's an advance pressure transducer than traditional mechanical pressure transducer. ±2%FS small output error, including nonlinear, hysteresis error and repeatability, full temperature range. Light weight and small size, convenient to install and operate. It has complete surge voltage protection function. Works for oil, fuel, diesel, gas, water, air pressure, can be used in oil tank, gas tank, diesel tank etc.Specifications:Material: Stainless steelVoltage: DC 5VPressure: 150 psiThread Type: 1/8" NPTInput: 0-150 psiOutput: 0.5-4.5V linear voltage output. 0 psi outputs 0.5V, 75 psi outputs 2.5V, 150 psi outputs 4.5VWorking Current: ﹤=10 mAThread: 1/8" NPTWiring: Red for +5V; Black for ground; Green for signal outputThe Biggest Pressure: Double the working pressureDestroy Pressure: Triple the workingMeasuring Error:+_ 1.5%FSOTemperature Range Error: +_ 3.5%FSOProtection Class: IP67Pressure Medium: Oil, gas and water which is compatible with 316L stainless steelLoad Resistance: less then (supply power-6.5V/0.02A)ΩResponse Time: =2.0 msInsulation Resistance: over 100mΩ 500VDCPackage Includes:1 x Pressure Transducer (With cable)

• 1.Product replacement parts
• 2.Please refer to the detailed description for compatibility
• 3.Real picture
• 4.The contents of the package are consistent with the picture
• 5.Condition new
